Impact screwdriver and bolt driver Bosch GDX 18V-285 285Nm

Bosch Professional GDX 18V-285 – impact screwdriver and bolt driver (285 Nm, 2-in-1)

Bosch GDX 18V-285 is a universal impact screwdriver and bolt driver that combines comfort, performance and durability. The 2-in-1 tool holder (¼” hex + ½” square) allows you to turn both screws and bolts with the same tool, reducing the number of tools and saving time on site.

A torque of 285 Nm allows you to fasten even larger bolts up to M18 size. With two levels of speed and torque, you can choose the most accurate setting according to the nature of the work. The easy-to-handle, narrow handle and compact design make the device comfortable for longer work both indoors and outdoors.

Characteristics

2-in-1 tool holder: ¼” hex and ½” square

Maximum torque 285 Nm

Starting torque up to 500 Nm

Two speed and torque levels:

level: 0-200 Nm and 0-2000 rpm

level: 0-285 Nm and 0-2800 rpm

Stroke frequency up to 3,600 min⁻¹

Brushless motor for better performance and durability

Comfortable and narrow cushioned handle

Suitable for all Bosch Professional 18V batteries

Applications

GDX 18V-285 is suitable for both screwing and bolting in construction, metalwork, installation and the workshop.

Optimized for bolting: M8, M10, M12

It is also possible to attach up to M18 bolts

Suitable for self-tapping screws (4.2 mm and 4.8 mm)

Suitable for wood screws (4 mm, 5 mm, 8 mm)

For screws M6, M8, M10

Technical data

Torque: max 285 Nm

Starting torque: max 500 Nm

Torque steps: 2

Idle speed: 0-2,800 rpm

Stroke rate: 0-3,600 min⁻¹

Idle speed level 1: 0-2000 rpm

Idle speed Level 2: 0-2,800 rpm

Pulse rate level 1: 0-3,000 min⁻¹

Pulse rate level 2: 0-3,600 min⁻¹

Battery voltage: 18 V

Weight without battery: 1.1 kg

Accessory adapter: ½” square + ¼” hex

Package dimensions: 360 × 444 × 151 mm
